Our solution offers a triple connectivity thanks to Satellite ECOSTAR 21, LoRaWAN, and Bluetooth Low Energy or Zigbee.
Easily collect data from your sensors, whether through a wired connection or Bluetooth. Transmit this data in real-time via a terrestrial or satellite link, ignoring the white zones of terrestrial networks.
Enjoy a low-cost subscription and a very energy-efficient solution.
Documentations :
| Dimensions | 180 x 90 x 70 |
| Weight | 585 grams |
| Material | Polypropylene |
| Ingress Protection | IP66 |
| Power Supply | 2 AA 1.5V alkaline batteries or 10/30V DC |
| Consumption | Standby: 25 µA Emissions: 320 mA maximum |
| Typical Battery Life | 10,000 messages |
| Inputs | Analog 4-20 mA Resolution 0.06 mA: 1 Analog 10/30V – Resolution 0.1V: 1 Dry Contact 8/30V opto-isolated: 2 Measurement frequency: Configurable via Bluetooth up to 1 kHz |
| Outputs | Active Dry Contact 0: 1 Relay: 2 |
| User Interface | RGB LED: 1 Push button: 1 |
| Transmission Frequency | Configurable via Bluetooth up to 1/hour |
| Emission Power | Auto-adaptive up to 27 dBm in S Band |
| Latency Time | 0 – Real-time |
| Antenna | Internal |
| GPS | |
| Operating Temperature | -30/+70°C |
| Storage Temperature | -40/+85°C |
| Configuration | Via mobile application for smartphones or tablets for Android and iOS |
